A low-pass filter is a filter that passes low-frequency signals and attenuates (reduces the amplitude of) signals with frequencies higher than the cutoff frequency. Low-pass filters provide a smoother form of a signal, removing the short-term fluctuations, and leaving the longer-term trend.
Share:
Description:
A low-pass filter is a filter that passes low-frequency signals and attenuates (reduces the amplitude of) signals with frequencies higher than the cutoff frequency. Low-pass filters provide a smoother form of a signal, removing the short-term fluctuations, and leaving the longer-term trend.
Features:
1. High rejection, low pass, and excellent return loss
2. Solid machined brass housing with nickel plating
3. 100% quality inspection.
| Specifications:Low Pass Filter(LPF-456) | |||
|
Frequency (MHz) |
10-438 |
438-460 |
480-770 |
|
Insertion Loss(dB)Max |
1.5 |
3.5 |
— |
|
Rejection(dB)Min |
— |
— |
40 |
|
VSWR(dB)Max |
1.8 |
1.8 |
— |
|
RFI(dB) |
-120 |
||
|
Impedance |
75Ohm |
||
|
Wateproof Test(Min) |
10 PSI |
||
|
Operating Temperature |
-40 degrees C to +60 degrees C |
||
|
Corrosion Resistance |
Meets SCTE/ANSI Specification |
||
